Energy Prism
3 / 30 / 30,000
The Energy Prism’s AMCs are engineered to deliver up to 3 cycles per day over a 30-year design life, equivalent to approximately 30,000 cycles in normal running conditions.
The Containerised DC Block
Energy cells can be integrated into the Energy Prism - a 20ft container-based IP54 solution for design-and-drop ease. Integrators can connect power conversion systems (PCS) to complete an AC system while using their preferred partners and technologies.
600 kWh. NO FIRE SUPPRESSION. NO COMPLEX THERMAL MANAGEMENT.
600 kWh
Usable Capacity
A 20 ft container of up to 600 kWh at 1200 V. Pre-integrated AMC, BMS, and wiring - compact and site-ready.
Zero
Fire Suppression
AMC chemistry eliminates fire suppression systems entirely - reducing cost, complexity, and permitting time.
30,000
Cycle Life
AMCs engineered for up to 3 cycles per day over a 30-year design life - approximately 30,000 total cycles.
Not Required
Thermal Management
Forced air cooling, supported by low-power HVAC when necessary. No chillers, no unnecessary points of failure.
Specifications
Energy Prism - Technical Specifications
DESCRIPTION
SPECIFICATION
Dimensions (W × D × H)
6058 x 2438 x 2896 mm
Total Designed Weight
20,000 kg ± 8%
Rated Energy
Up to 600 kWh
Nominal Voltage
1075-1450V, 387-522V for UPS
System Voltage
1200V, 480V for UPS
Maximum Charge/Discharge Rate
C/24 ~ 0.55C
Temperature
-10°C to ~ +45°C ; max. temp up to 60°C
IP Ratings
IP54
Altitude
≤ 2000 m
Cooling Type
Forced Air*
Communication Protocol
TCP/Modbus
BMS
Integrated
Certifications
UL 9540, IEC 62933-5-2
* Supported by Low-Power HVAC when necessary
Container Integration
Fully assembled. Fully integrated.
Energy Racks are integrated into the Energy Prism - a container-based solution for design-and-drop ease. Integrators connect power conversion systems (PCS) to complete an AC system using their preferred partners and technologies. Unlike conventional container solutions, fire suppression is not required.
Get Started
Ready to spec your project.
The Energy Prism datasheet includes full electrical, mechanical, and environmental specifications. For project-specific configurations, our team can model your requirements.
